When success rides on the perfect shot, rely on the exceptional versatility and optical performance of Viper® HD. From big game to predators, there's a proven model for every hunting application. Each member of the Viper® HD family delivers outstanding image clarity, resolution, and sharpness to ensure your target comes into view with sharp detail. Viper® HD also boasts enhanced features for unmatched accuracy at extended ranges while also excelling in the low light of dawn and dusk when game is most active.
PRODUCT SPECIFICATIONS:
Magnification: 5-25x
Objective Lens Diameter: 50 mm
Focal Plane: Second Focal Plane
Reticle: VMR-3 (MRAD)
Turret Style: Exposed Elevation Capped Windage
Tube Size: 30 mm
Adjustment Graduation: .1 MRAD
Parallax Setting: 20 yds. - 8
Max Windage Adjustment: 12.4 MRAD
Max Elevation Adjustment: 20MRAD
Travel Per Rotation: 10 MRAD
Total Elevation Adjustment w/ RevStop® installed: 18.9 MRAD
Field of View: 24.0' - 4.7'
Eye Relief: 3.4"
Length: 15.2"
Weight: 25.0 oz
PRODUCT FEATURES:
HD Optical System: Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration and provide outstanding color fidelity, edge-to-edge sharpness and light transmission.
Illuminated Reticle: Provides precise aiming under low-light conditions.
30mm Main Tube: For increased travel.
Exposed Locking Elevation Turret: Integrated locking mechanism prevents accidental adjustments. Elevation turret provides fast, accurate, easily read elevation adjustments.
RevStop® Zero System: For a rock-solid return to zero after turret adjustments.
Fully Multi-Coated Lenses: Anti-reflective coatings on all air-to-glass surfaces provide increased light transmission for greater clarity and low-light performance.
ArmorTek®: Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
Argon Gas Purged: Gas purged and O-ring sealed for fogproof and waterproof performance in all conditions.
Fast Focus Eyepiece: Allows quick and easy reticle focusing.
Aircraft-Grade Aluminum: Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
Low Glare Matte Black Anodize: Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position.
Single-Piece Tube: Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
Waterproof: Designed to withstand harsh weather conditions.
Fogproof: Nitrogen gas purging prevents internal fogging over a wide range of temperatures.
Shockproof: Designed to withstand the highest levels of recoil and impact.
